CAL102
More than just a measuring device, the Precision Ultrasound Balance is a complete calibration system, supporting a wide frequency range and delivering fine resolution measurements. Its compact size and protective carrying case make it highly portable, while the RS232 interface ensures it can be seamlessly integrated into digital reporting systems.
The inclusion of a certificate of conformity and the option for calibration traceable to UK National Standards further reinforces its professional-grade reliability. With quick warm-up times and stable performance over extended use, the device has been carefully developed to meet the needs of both laboratory environments and on-site servicing, ensuring engineers can maintain equipment accuracy with confidence and efficiency.
Specification
| Accuracy (scale factor) | ±10% |
| Resolution | 0.02 watts |
| Linearity | <0.1 watts |
| Stability | <0.1 watts / 10 minutes |
| Zero Drift | <0.1 watts / hour |
| Warm-up Time | <10 minutes |
| Full Scale | 30 watts |
| Dimensions | 222 × 300 × 300 mm |
| Weight | 1.4 kg |
| Water Capacity | 1 litre |
| Recommended Frequency Range | 0.8 – 3.5 MHz |
Key Features
- Calibration traceable to UK National Standards available
- High accuracy of ultrasound output measurement
- Repeatable measurements to laboratory standards
- Compatible with EMS Physio models and other ultrasound units
- Simple to assemble and operate
- Suitable for both laboratory and field use
- Supplied with protective carrying case
- RS232 interface included as standard
- Certificate of conformity provided
